EXQUISITE DESIGN
THE PUMP IS COMPACT AND EASY TO USE
MPPT FUNCTION
THE SOLAR POWER UTILIZATION RATE IS HIGHER
HIGH EFFICIENCY
COMPARED TO BRUSHLESS MOTORS,THE EFFICIENCY IS IMPROVED BY 25%
SPECIFICATIONS
| MODEL | Voltage | Best InputVoltage | Power | Max. Flow | Max. Head | Outlet | Cable | SOLAR PANEL | Power |
| (V) | (DC) | (W) | (m³/h) | (m) | (In) | (m) | Open voltage | ||
| 4TY4-22/4-600W/60V | 60V | 60-84V | 600W | 6.5 | 42 | 1.25/1.5" | 2m | <100V | ≥720W |
| 4TY4-30/6-750W/72V | 72V | 72-124V | 750W | 6.5 | 56 | 1.25/1.5" | 2m | <150V | ≥900W |
| 4TY4-39/9-900W/96V | 96V | 96-124V | 900W | 6.5 | 72 | 1.25/1.5" | 2m | <150V | ≥1080W |
| 4TY4-52/12-1200W/110V | 110V | 110-164V | 1200W | 6.5 | 95 | 1.25/1.5" | 2m | <200V | ≥1440W |
| 4TY4-67/14-1500W/110V | 110V | 110-164V | 1500W | 6.5 | 116 | 1.25/1.5" | 2m | <200V | ≥1800W |
| 4TY4-67/14-1500W/150V | 150V | 150-205V | 1500W | 6.5 | 116 | 1.25/1.5" | 2m | <400V | ≥1800W |
| 4TY4-100/20-2200W/200V | 200V | 200-330V | 2200W | 6.5 | 155 | 1.25/1.5" | 2m | <450V | ≥2640W |
