High lift &Large flow

All copper wire motor

Security and stability

PRODUCT FEATURES

Small size, low weight, small area occupation, easy assembly;Direct connection between pump and motor,tight structure, easy transportation;

Classic style, good looking and anti-corruption, long service life;

Engineering plastic nylon seat, anti-friction and anti-corrosive;

PRODUCT APPLICATION

The pump can be applied for country well water drawing, farmland irrigation. household water supply, breed industry oxygenation and water supply and drainage, farmland long distance water supply, garden irrigation and hotel.restaurant and high-rise building water supply;

PUMP/MOTOTR CONFIGURATION

Cast iron pump, electrophoresis processed connection;

Aluminum/plastic impeller available;

304 stainless welded spindle;

Cast iron motor body, upper cap;

C&U bearing;

Copper motor winding;

Inner overheat protection device;

Insulation grade: B;

Protection level: IP68;

OPERATION CONDITION

The pump can be continuously functional under the conditions below Media temperature no more than +50°C;PH value of media shall be around 5-8.5;Maximum solid impurity size no more than0.1%, particle size no more than 0.2mm;Power source frequency50Hz, power voltage 380V, voltage fluctuation ranges ±10% of rated value;Diving depth no more than 5m.
